Cylinder phoshoric acid of lithium iron batteries

Using LiFePO4 as anode material, with mean voltage over 3.2V and plantform capacity over 90%.
Long cycle life,cycling capacity above 80% after 1500times of cycles at 1ltA rate,and over 500cycles at high rates discharge of 10ltA.
Good performance of charge and discharge at high temperature:capcaity at +55°C can be over 90% of that at room temperature.

Cylinder Li(LiCoMn)lithium batteries

Using lithium Li(LiCoMn)as positive materials,excellent discharge performance with capacity more than 80% over 500 cycles.
High discharge platform,normally over 3.7V, and over 3.6V at high rate of discharge.
Super low temperature performance,can be discharged continuously at -40°C.

Main Application

Our Li-Ion battery is safe and green without any metal pollution like cadmium,lead or mercury etc.,is mainly used on lighting equipment,emergency lighting,aerospace,military,telecom industry,medical equipment,portable computer,digital products,electric vehicles,electric tools,electric toys,public facilities,and other portable devices.

Lithium-ion Disposable batteries

No.	Items	Specification
1	Battery system	Lithium and Iron Disulfide Battery(Li/FeS2)
2	Nominal Voltage	1.5 V
3	Rated Capacity	3400 mAh at 48ohm(Ω) discharge,E.V=0.8V
4	Working Voltage	1.30V @ 200mA discharge rate
5	Max. pulse Discharge Current	4000 mA (2 sec on /8 sec off)
6	Max. continuous discharge current	2500mA
7	Discharge Cut-off Voltage	0.80V
8	Volume	8.0 cubic centimeters
9	Weight	Approx. 14.50 g
10	Dimensions	Diameter:	Minimum: 13.70 mm ± 0.05 mm
			Maximum: 14.35 mm ± 0.05 mm
		Height:	Minimum: 49.20 mm ± 0.05 mm
			Maximum: 50.50 mm ± 0.05 mm
11	Operating Temp.	-40 ℃ to 60 ℃
12	Storage/Shipping Temp.	-20 ℃ to 40 ℃
13	Storage/Shipping Humidity	≤75 %
14	Shell Life	10 Years

No.	Items	Specification
1	Battery system	Lithium and Iron Disulfide Battery(Li/FeS2)
2	Nominal Voltage	1.5 V
3	Rated Capacity	1400 mAh at 48ohm(Ω) discharge,E.V=0.8V
4	Working Voltage	1.30V @ 100mA discharge rate
5	Max. pulse Discharge Current	1500 mA (2 sec on /8 sec off)
6	Max. continuous discharge current	1000mA
7	Discharge Cut-off Voltage	0.80V
8	Volume	3.80 cubic centimeters
9	Weight	Approx. 7.50 g
10	Dimensions	Diameter:	Minimum: 9.50 mm ± 0.05 mm
			Maximum: 10.50 mm ± 0.05 mm
		Height:	Minimum: 43.30 mm ± 0.05 mm
			Maximum: 44.50 mm ± 0.05 mm
11	Operating Temp.	-40 ℃ to 60 ℃
12	Storage/Shipping Temp.	-20 ℃ to 40 ℃
13	Storage/Shipping Humidity	≤75 %
14	Shell Life	10 Years

Lithium-ion Rechargeable batteries List

Series	Type	Typical Capacity (mAh)	Max Weight (g)	Nominal Voltage	Figuration Dimension
Series	Type	Typical Capacity (mAh)	Max Weight (g)	Nominal Voltage	Dia (mm)	Height (mm)
Li(NiCoMn) Lithium Battery	INR18650	2200	42	3.7V	18.0±0.2	65.0±0.5
	INR22430	2100	43	3.7V	22.0±0.2	43.0±0.5
	INR26650	4500	92	3.7V	26.0±0.2	65.0±0.5
Lithium-ion Phosphate Battery	IFR18650	1400	39	3.2V	18.0±0.2	65.0±0.5
	IFR22430	1400	41	3.2V	22.0±0.2	43.0±0.5
	IFR26650	3200	84	3.2V	26.0±0.2	65.0±0.5
	IFR2265100	11000	295	3.2V
Manganese Acid Lithium Battery	IMR18650	1600	38	3.7V	18.0±0.2	65.0±0.5
	IMR22430	1600	39	3.7V	22.0±0.2	43.0±0.5
	IMR26650	3200	82	3.7V	26.0±0.2	65.0±0.5
